11.2.2 Firmware until 6x.45, 37.60
Push Display (Example) Description
0 Vaa.bb 01.05.17 aa = Reader Protocol Version
37 - Wiegand, 60 - Lbus, 61 - BG900, 62 - OSDP
bb = Firmware Version
01.05.17 release date of the firmware (dd.mm.yy)
1 S/N1: 0910024419 Serial number 18 digits - Part1 10 digits
2 S/N2: 22850034 Part 2 - 8 digits
3 11.18 12:24:18 S Current date and time (MM.DD hh:mm:ss)
(S) = daylight saving
4 Dig. IO: :::::::::::::::: Display of the digital contacts: the input signals set will
be shown with an extension above - output signals with
an extension below. The first eight digits display the
controller’s signals. The second eight digits display the
extension board’s signals
4a Dig. I1: ::::::::::::::::
If there are I/O-Boards connected, the signals will
be shown on separate pages.
4b Dig. I2: ::::::::::::::::
4c Dig. I3: ::::::::::::::::
5 MAC 001B860012AB Network device address (MAC)
6
N AMC-1234-5678
Network name of the controller (max. 14 char.)
See Configuring Ethernet interface, page 34 .
7 I 192.168.10.18 IP-address of the controller
8 G 192.168.10.255 IP-address of the gateway
9 M 255.255.255.0 Subnetmask
10 H 192.168.10.10 IP-address of the host computer
11 DHCP 1 DHCP-status:
1 = on
0 = off
12 D 192.168.10.1 IP-address of the DNS server
13
Host: + "C"
Host activity:
+ = online
- = offline
"C" = Counter (0 to 9) of the received data packages
from the host interface.
RS-485 Bus connection:
A = Address 1 … H = Address 8
14 HSC state: x Host secure status:
1 = enable
2 = disable
