Hardware
2--20
1070 072 196-101 (00.06) GB
2.7 Status Display
Each channel of the COM-E module is provided with a status display. It
shows all channel-related statuses and error messages.
These messages are assigned directly to the corresponding channel, and
thus to this protocol.
Lower
Display
Upper
Display
Explanation
0to3 H Hardware error
4 H No Ethernet address
5 H Reserved
0toF * Faulty jobs channel 1 (Ethernet)
* 0toF Faulty jobs channel 0 (V.24/20 mA)
* P No protocol set for channel 0 (monitoring is possible)
* ‘-‘ Job listing (monitoring/tracer) on
* ‘_’ Error listing on
* ‘-.‘ Data output with job listing
* ‘_.’ Data output with error listing
U * No IP address set
n * No configuration file loaded
* . Centralized job runs at channel 0
. * Centralized job runs at channel 1
* C Software error
C A Wait for system logon, wrong block address, no entry of
the module in the SK table
* C Reserved
0toF off Hangman, with output of a 3-digit string
