General Information Regarding BUEP-E and BUEP19E
7--13
1070 072 196-101 (00.06) GB
7.3 Error Messages
The BUEP-E protocol creates error information that is divided into three
areas:
D PLC reaction (byte)
D Error class (byte)
D Error code (byte)
The error information is filed in the feedback parameter of the R5CON in the
following order:
7.3.1 Parameter 3, Status / PLC Reaction R5CON
High Byte Low Byte
Code
[hex]
Job Status Code
[hex]
PLC Reaction
00 Job is finished (completed) without error 00 Operation without error
01 Job on the RSS is being processed 01 Repeat call of FM R5CON
02 Job in queue of RSS 02 Change PLC program
03 Job is finished with error 03 Check and change job parameter
04 No job with this job number is being processed 04 Process FM R5INIT again
05 Process FM R5REQ again
06 Process FM R5CON again
50 Undefined error code, reaction not possible
