R5REQ
5--2
1070 072 196-101 (00.06) GB
5.2.1 Input Parameters
P0
Parameter Attribute Description
P0 W Data type
This parameter determines the type of a data area. Here, for each job, a data
storage area of 16 words is reserved for the protocol-specific parameters.
Possible data storage areas are:
D Data module 44
H
D Data buffer 64
H
D Data field 43
H
The user must always reserve 16 words per job for job-specific parameters.
P1
Parameter Attribute Description
P1 W Data type attribute
If a data module is determined by P0 as a data storage area, P1 indicates the
data module number. In other cases, P1 is meaningless, and should be re-
served with 16#FFFF.
Applicable values are:
D 0to511
D 16#FFFF
P2
Parameter Attribute Description
P2 W Byte offset
This is the location where the start address for the job parameters in the se-
lected data storage area is determined.
