General Information Regarding BUEP-E and BUEP19E
7--15
1070 072 196-101 (00.06) GB
7.3.3 Catalogue of Errors
The PW column contains the parameter which has probably caused the
error.
Error Information [hex] Explanation
Reaction Class Code PW
00 00 00 Error-free job
Error during command execution on one’s own AST module
Error Information [hex] Explanation
Reaction Class Code PW
01 30 21 RUN error. The module is in the RUN state. The specified command
cannot be executed, AST
01 30 22 Change of operating mode not possible, AST
03 30 23 4, 5 AST field access not permitted; the desired access (read/write/bit) is not
applicable for this field.
01 30 24 AST field protection active; at the moment, the desired field is reserved
by another position
01 30 25 Timer disabled; actual time values can only be changed when time is
running
03 30 26 6 AST module number too large; larger than the allowed maximum value
03 30 27 6 AST data module not available, in the application program
03 30 28 8, 12 AST data module too small, in the application program
03 30 2B Data Error during writing to the system clock
01 30 E0 to FF Reserved for system bus error
01 33 02 Memory access error
03 33 03 4 Wrong memory type; e.g. writing on EPROM memory
03 33 10 7 No module exists for the specified AST block address
03 33 18 5 Unsupported command code; unequal to D/DB/DF/M
03 33 19 4 Type of command neither E nor A
03 33 20 5 AST command code undefined
03 33 3A 4, 8 Wrong address orientation, e.g. writing a word on odd addresses
03 33 3B 8 Invalid address range
03 33 3C e.g. 6 Invalid parameter
03 33 3D Invalid type of operand
03 33 63 Buffer overflow, amount of data too much
01 34 05 Server does not respond; Time-out
01 34 06 Server not found; no ARP
03 34 07 14, 15 No server found for specified IP address
01 34 08 No IP address entered on the module
