Menu structure
17
Control 8313 – 6720859567 (2017/03)
9 Menu structure
The control unit electronics have 2 levels, in which system-dependent
settings are made. The levels and parameters displayed depend on the
installed modules and the factory defaults. The parameters that are not
required for the selected function are not displayed.
Parameters that are not active are highlighted in grey.
The functions of the most frequently used modules FM-MM, FM-MW and
FM-SI are described in these instructions, in addition to the basic
functions of the control unit.
Chapter 6 from page 11 describes how to operate and call the menus
with the user interface.
In the following tables, the default settings are highlighted in bold in the
"Settings/Adjustment range" column.
Table 5 Main menu
Main menu Explanation/Function Further information
General
characteristic data
Settings of the control unit, of heating system parameters and the house properties chapter 9.1, page 18
Module selection For selecting whether modules are detected and installed automatically or manually chapter 9.2, page 18
Boiler
characteristics
Setting of different boiler data, depending on heat source
If a FM-SI is installed: settings for the safety equipment.
chapter 9.3.1, page 19
Heating circuit data Setting of different heating circuit data (e.g. heating circuit system, maximum flow temperature)
and display of current heating curves of the relevant heating circuit
chapter 9.4.1, page 21
chapter 9.5, page 27
Domestic hot water Water treatment settings chapter 18, page 27
Reset Reset values in the main menu and service menu to the default settings. chapter 14, page 37
Version Shows the software versions of the user interface, the control unit and the Open Source information Chapter 2.2, page 5,
chapter 15, page 37
Control unit Save or load configurations chapter 20.1, page 44
Connectivity Activation and setting of network connection Chapter 9.6, page 28
Chapter 9.6, page 28
Function test Check whether system components (e.g. pumps) are correctly connected.
The displays depend on which modules are installed. Depending on the operating conditions, there may
be a time delay between the demand and display.
chapter 17, page 43
Lock screen Option for locking the screen. chapter 9.7, page 29
Manual operation When the key is pressed, the heat source operates using stored values. chapter 7.3, page 15
Monitor data Shows set values and actual values of the system. Tap the symbol to display the values in the
bottom bar.
chapter 19, page 44
Fault Shows the faults in the heating system. The user interface can only display the faults for the
control unit it is connected to.
chapter 11.3, page 32
Chapter 20.5, page 45
and chapter 20.6,
page 45
