Menu structure
21
Control 8313 – 6720859567 (2017/03)
9.4 Heating circuit data
The heating circuit on the central module (PK, SR, FZ) can be used either
as a heating circuit with mixer or as a boiler circuit. If a system
component is used in a function, the other system components can no
longer be used for the other function.
Example: if SR is used as the mixing valve for the boiler circuit, PK cannot
be used for a heating circuit without mixer.
When used as a heating circuit, this is displayed as heating circuit 00.
Only the heating circuits that are available via modules are displayed.
The heating circuit symbols turn grey if heating circuits are available but
not active. If heating circuits are available and active, the heating circuit
symbols are displayed normally in white.
Display of heating circuits
The designation assigned to the heating circuits depends on the slot of
the heating circuit module. The heating circuits are numbered according
to the sequence of slots. This means that the heating circuits at slot 1 are
displayed as heating circuit 01 and 02. The heating circuits at slot 2 are
displayed as 03 and 04. If a different module is inserted at a slot, these
heating circuit numbers are omitted.
If a name has been assigned to the heating circuit, this is displayed.
9.4.1 Basic setting
Submenu Settings/
adjustment range
Explanation Note
Heating circuit Off/On
Heating circuit name Heating circuit
name
• Basement
• Apartment
• Swimming pool
• Building
• Underfloor
Heating
• Floor
You can choose the name of the heating circuit
from a list or give it your own name.
Heating system Radiator/
Underfloor
Heating
The type of heating system determines the
gradient or curvature of the heating curve.
Chapter, 12, page 33
Constant
Base Point
Room
Damping influence of outdoor
temperature
0...100 % Setting that determines the extent to which the
adjusted outside temperature affects the
control parameter.
Chapter, 12, page 33
Remote Control No/Yes Determines whether a remote control is
installed for the heating circuit that influences
the heating circuit.
Chapter 12.1.1, page 33
Underfloor Heating Off/On
Maximum underfloor flow
temperature
20...45...60 °C This value specifies the temperature above
which the flow temperature must not rise.
The value set influences the heating curve.
Maximum flow temperature 30...75...120 °C This value specifies the temperature above
which the flow temperature must not rise.
The maximum flow temperature depends on the
heat source and is therefore limited by the heat
source.
Minimum flow temperature 5...70 °C Limiting the heating curve to a minimum set
value
This value sets the temperature below which
the flow temperature must not drop.
This parameter cannot be adjusted with the
Constant heating system.
▶ Only change value if necessary.
Actuator No/Yes Information as to whether or not the system is
equipped with a heating circuit mixing valve
If the heating circuit is equipped with a heating
circuit mixing valve, this is activated by the
control unit.
The heating circuit is regulated via the flow
temperature of the heat source if no heating
circuit mixing valve is installed. No heating circuit
mixing valve is entered for heating circuit 00.
