Menu structure
Control 8313 – 6720859567 (2017/03)
18
9.1 General characteristic data
Table 6 General characteristic data menu
9.2 Module selection
When the control unit is switched on or after a reset, the modules are
automatically recognised and their information downloaded.
If the modules are not recognised automatically:
▶ Set the modules manually.
Table 7 Module selection menu
Submenu Settings/
adjustment
range
Explanation Note
Language Selection of language of texts displayed.
Date format Selection of date format
Calendar Entry of date
Time Entry of time
Time Zone Europe/Berlin Regional zone where the same time applies
Europe/London
Europe/Paris
Europe/Moscow
Universal time/
Greenwich Mean
Time
Minimum outdoor
temperature
–30...–10...0 °C The minimum outside temperature is the average
of coldest outside temperature recorded in each
previous year.
▶ For regional average minimum outside
temperature values, refer to tab. 23
( Chapter 10.1, page 30).
Building Light Poor heat storage capability, e.g. pre-fabricated
houses, wooden-framed constructions
▶ Adapt heating system to the construction
( Chapter 10.2.1, page 30).
Medium medium heat storage capability,
e.g. house built with hollow blocks
Heavy High thermal storage capacity,
e.g. house made of bricks
Insulation standard Small No or minimum insulation effect, e.g. house
without insulation
▶ Adapt heating system to the insulation
situation ( Chapter 10.2.2, page 30).
Medium Medium insulating effect, e.g. house with 10 cm
mineral wool
Good Large insulating effect, e.g. new build or
renovated house with 20 cm mineral wool
Outside temperature source ZM The outside temperature sensor is connected to
this control unit.
The parameter is only displayed with control
units with address > 0 (e.g. substations).
Control unit 00 The outside temperature sensor is connected to a
different control unit. The sensor values are
transmitted via the BUS.
External heat demand None
Off/On WA1/3 closed = external heat demand on
Temperature Specifies the effect the 0...10 V input (WA1/2) is
to have on the system.
Chapter 10.3.1, page 31
Output Specifies the effect the 0...10 V input (WA1/2) is
to have on the system.
Chapter 10.3.2, page 31
Submenu Settings/adjustment range Explanation Note
Slot A ZM5313 Automatic recognition and
installation of the modules for slot A
Slot for boiler module
Slot 1...4 None Slots for function modules and
auxiliary modules
Module selection The installed modules can be
selected from a list.
