Appendix
49
Control 8313 – 6720859567 (2017/03)
23 Appendix
23.1 Technical data
23.1.1 Control unit specifications
Table 28 Control unit specifications
23.1.2 FM-MM function module specifications
Table 29 FM-MM function module specifications
23.1.3 FM-MW function module specifications
Table 30 FM-MW function module specifications
23.1.4 FM-SI function module specifications
Table 31 FM-SI function module specifications
Unit CC 8313
Dimensions B/H/L mm 653/274/253
Operating voltage (at 50 Hz ±4 %) V 230 ±10 %
Power consumption W 5
Control unit fuse protection A 2 x 10
IP rating – III
Protection class – IP X0D
Maximum switching current
• Pump outputs A 5 (30 A for 10 ms)
Ambient temperatures
• Operation
• Transport and storage
°C
+5...+50
–20...+55
Unit FM-MM function module
Operating voltage
(at 50 Hz ± 4 %)
V AC 230 (± 10 %)
Power consumption W 1
Heating circuit mixing valve
(SH):
Max. switching current
Activation
Recommended servomotor
running time
A
V
s
5
230
three-point stepper
controller
(PI-characteristics)
120
(adjustable from
10 ... 600)
Maximum switching current
• Pump outputs
A 5
Temperature sensor
1)
NTC sensor Ø
1) Max. cable length 10 m
mm 9
External optional function WF
Contact load
DC/mA
Potential-free input
5/10
Unit FM-MW function module
Operating voltage
(at 50 Hz ± 4 %)
V AC 230 (± 10 %)
Power consumption W 1
Heating circuit mixing valve
(SH):
Max. switching current
Activation
Recommended servomotor
running time
A
V
s
5
230
three-point stepper
controller
(PI-characteristics)
120
(adjustable from 6 ... 600)
Maximum switching current
• Pump outputs
A 5
Temperature sensor
1)
NTC sensor Ø
1) Max. cable length 10 m
mm 9
External optional function WF
1)
Contact load DC/mA
Potential-free input
5/10
Unit FM-SI function module
Operating voltage
(at 50 Hz ± 4 %)
V AC 230 (± 10 %)
Power consumption W 1
SI1...SI5 inputs V AC 230 (± 10 %)
