Bosch Control 8313 Service Instructions For Contractors

Appendix
Control 8313 – 6720859567 (2017/03)
50
23.2 Sensor curves
DANGER:
Danger to life due to electric shock!
Before opening the device:
▶ Isolate the mains voltage.
▶ Secure against unintentional reconnection.
Checking fault:
▶ Remove sensor terminals.
▶ Check the resistance at the temperature sensor cable ends
using an ohmmeter.
▶ Check the temperature at the temperature sensor with
a thermometer.
The following tables show whether the temperature and pressure
drop value correspond.
The sensor tolerance for all curves is ± 3 % at 25 °C.
23.2.1 Pressure drop values for outside, room, flow and hot water
temperature sensors
Table 32 Pressure drop values of 53xx temperature sensor
23.2.2 Pressure drop values for boiler water temperature sensor
and flue gas temperature sensor with EMS floor standing
boiler with SAFe burner control unit
Table 33 Pressure drop values for boiler water temperature sensor and
flue gas temperature sensor of EMS floor standing boiler with
SAFe burner control unit
Temperature [ °C] Resistance []
–40 332100
–35 240000
–30 175200
–25 129300
–20 95893
–15 72228
–10 54889
–5 42069
0 32506
5 25313
10 19860
15 15693
20 12486
25 10000
30 8060
35 6536
40 5331
45 4372
50 3605
55 2989
60 2490
65 2084
70 1753
75 1480
80 1258
85 1070
90 915
95 786
100 677
110 508
115 443
120 387
Temperature [ °C] Resistance []
–10 50442
–5 39324
0 30902
5 24495
10 19553
15 15701
20 12690
25 10291
30 8406
35 6912
40 5715
45 4744
50 3958
55 3312
60 2786
65 2357
70 2004
75 1709
80 1464
85 1257
90 1084
95 939
100 816
105 711
