Electrical connection
23
Compress 5800i AW – 6721862724 (2023/06)
Fig. 30 Electrical connections
[1] 400V ~3N input to indoor unit
6.10.5 Terminal connections in electric box
Please note the jumper arrangement.
1
0010041725-003
L1 L2 L3 1PE 2PE 3PE 4PE 5PE 6PE 1L 2L 3L
1SL 2SL
3SL
1N 2N
3N
4N 5N
N
