15. Optical network sockets - Connects the central control unit to the optical network.
The DCN-CCUB2 Basic Central Control Unit controls the system. The basic central control unit
is a simplified version of the DCN-CCU2 Central Control Unit. The DCN-CCUB2 Basic Central
Control Unit:
– Has one XLR output.
– Does not have any XLR inputs.
– Does not have a fault contact.
– Cannot be connected to the optical network Controls, connectors and indicators.
The following sections give more information about the mentioned subject:
– Planning: Planning, page 64.
– Installation: 19 inch units, page 91.
– Connection: 19 inch Units, page 112 and DCN-CCU2 and DCN-CCUB2 Central Control
Units, page 113.
– Configuration: 19 inch units, page 179 and DCN-CCU2 and DCN-CCUB2 Central Control
Units, page 183.
– Operation: DCN-CCU2 and DCN-CCUB2 Central Control Units, page 231.
– Troubleshooting: DCN-CCU2 and DCN-CCUB2 Central Control Unit, page 261.
– Technical Data: DCN-CCU2 and DCN-CCUB2 Central Control Units, page 276.
Conference System System Overview | en 15
Bosch Security Systems B.V. Operation Manual 2013.11 | V2.0 | DCN-NG_OM_V4.x
