Power supply
You can connect an external power supply to the external power supply socket of the fiber
interface. The fiber interface is supplied with a Kycon KPP-4P plug, which you can connect to
this socket (refer to PRS-NSP Network Splitter, page 146).
Warning!
For safety reasons, you must use a current limited external power supply complying with the
60065 standard for audio/video usage or equivalent, with a maximum output current of 5A, or
you must use an external fuse (5A max, slow) in the wiring to the Kycon KPP-4P connector.
Max. 48V/5A
KPP-4P
Pin 1
KPP-4P
Pin 2
Figure 6.54: Power supply connection
150 en | Connection Conference System
2013.11 | V2.0 | DCN-NG_OM_V4.x Operation Manual Bosch Security Systems B.V.
