Pin Signal Wire
O1 Data Optical fiber
O2 Data Optical fiber
Table 6.37: Optical network connector details
E1
RED
E1
BROWN
E2
O1
BLACK (2x)
O2
E2
O1
O2
Figure 6.91: Wiring diagram
O1
O2
O1
O2
A
A
E1
E2
E1
E2
R
R
B
B
R
B
= Red
= Brown
Figure 6.92: Wiring diagram applied to type A optical network cables
