Figure 6.93: Wiring diagram applied to type B optical network cables
Where applicable, the procedure to assemble the connectors for both types of cable is shown
in the figures. Do as follows:
1. Make sure the ends of the cables and the plastic optical fibers correct.
A
B
A
B
R B
B R R
B
R B
R
B
= Red
= Brown
Figure 6.94: Copper wires and fibers
2. Put the ferrules in the mounting block.
A
B
Figure 6.95: Mounting block and back housing
