Mix-minus
Use the Mix-minus mode to connect via audio input and audio output 2:
– A telephone coupler.
– Two systems.
Notice!
The Mix-minus connection prevents acoustic feedback.
Ɖ
O
DC
DC
Ɖ
O
O
I
D
I
1
2
2
1
PC
PC
CCU
Figure 3.6: Mix-minus
Notice!
Use a telephone coupler, in case of long distances between the two systems
