Bosch rexroth HyDrotrAC GFt User Manual

RE 79094, Issue 10.2019, Bosch Rexroth AG
About this documentation | HYDROTRAC GFT >130 kNm  5/64
1 About this documentation
1.1 VALIDITY OF THE DOCUMENTATION
This documentation is valid for the following product:
• HYDROTRAC GFT >130 kNm
These general operating instructions of the HYDROTRAC GFT hydrostatic drive
describe the following congurations:
• Planetary gearbox with connection options for:
– Axial-piston motor
• Planetary gearbox (depending on the scope of supply) with :
– mounted axial-piston motor
– integrated static multiple-disk brake
– Disconnect mechanisms
f For the valid conguration of your hydrostatic drive HYDROTRAC GFT, see the
chapters “Product description”, “Scope of supply” and appendix D “Technical
data / Drawings” of the material number-specic operating instructions.
f Also observe the respective chapters of these general operating instructions.
For simplication purposes, the product is referred to as “HYDROTRAC GFT
planetary gearbox” or as “planetary gearbox” in the following chapters.
This documentation addresses installers/service technicians/machine or vehicle
operators.
This documentation contains important information on the safe and appropriate
transport, storage, assembly, commissioning, use, maintenance, disassembly and
simple troubleshooting of the planetary gearbox.
f Please read this documentation completely and in particular the chapter
2 “Safety Instructions” and chapter 3 “General information concerning damage
to property and product damages”, prior to working with the planetary gearbox.
1.2 REQUIRED AND SUPPLEMENTARY DOCUMENTATIONS
f Please only commission the planetary gearbox once the documentation marked
with the book icon
has been made available to you and make sure you have
read, understood and followed it.
Table 1: Required and supplementary documentations
Title Document type
Material number-specic operating
instructions
Operating instructions (included within
Rexroth's scope of supply)
CORRECTION COPY 1 |17.10.2019 | ONLY FOR INTERNAL USE
