About this product | HYDROTRAC GFT >130 kNm 21/64
The indicated gear type is an example. Your HYDROTRAC GFT planetary gearbox may
differ from this example in the following points:
• Position and type of the connections
• Position of oil ller opening
• Position of the oil level control system
• Position of the oil drain opening
• Position and type of mounting parts
• Optional disconnect mechanism (deactivation)
5.5 IDENTIFICATION OF THE PRODUCT
A name plate is located on the planetary gearbox, enabling you to identify the
product.
5.5.1 Standard name plate
The following information is indicated on the name plate:
Fig. 3: Example of a planetary gearbox name plate
1 Internal factory code
2 Date of manufacture
3 Product material number
4 Serial number
5 Factory specic order number
6 Ratio of the gearbox
7 Type code
8 Customer material number
9 Manufacturer
The name plate shown above is only an example of the Rexroth name plate.
In addition, the serial number is engraved on the gearbox housing. For this
information, please refer to the front side/motor connection side on the spindle.
9
8
7
6
5
1
2
3
4
