Bose FreeSpace DXA 2120

21
ELECTRICAL PART LIST
Resistors (continued)
Digital Signal Processor (DSP) PCB Assembly
Reference
Designator
Description Vendor Part Number Note
R318 10 OHM, RMG, 1/16W, 5%, 0603/1608 4723-100J+P 4
R320 10K, RMG, 1/16W, 5%, 0603/1608 4723-103J+P 4
R321 10K, RMG, 1/16W, 5%, 0603/1608 4723-103J+P 4
R322 10K, RMG, 1/16W, 5%, 0603/1608 4723-103J+P 4
R323 330 OHM, RMG, 1/16W, 5%, 0603/1608 4723-331J+P 4
R324 330 OHM, RMG, 1/16W, 5%, 0603/1608 4723-331J+P 4
R325 330 OHM, RMG, 1/16W, 5%, 0603/1608 4723-331J+P 4
R326 330 OHM, RMG, 1/16W, 5%, 0603/1608 4723-331J+P 4
R327 330 OHM, RMG, 1/16W, 5%, 0603/1608 4723-331J+P 4
R328 330 OHM, RMG, 1/16W, 5%, 0603/1608 4723-331J+P 4
R336 0 OHM, RMG, 1/16W, 5%, 0603 4723-000J+P 4
R337 0 OHM, RMG, 1/16W, 5%, 0603 4723-000J+P 4
R338 0 OHM, RMG, 1/16W, 5%, 0603 4723-000J+P 4
R339 0 OHM, RMG, 1/16W, 5%, 0603 4723-000J+P 4
R340 0 OHM, RMG, 1/16W, 5%, 0603 4723-000J+P 4
R341 0 OHM, RMG, 1/16W, 5%, 0603 4723-000J+P 4
R342 0 OHM, RMG, 1/16W, 5%, 0603 4723-000J+P 4
R343 330 OHM, RMG, 1/16W, 5%, 0603/1608 4723-331J+P 4
R344 330 OHM, RMG, 1/16W, 5%, 0603/1608 4723-331J+P 4
R345 330 OHM, RMG, 1/16W, 5%, 0603/1608 4723-331J+P 4
R346 330 OHM, RMG, 1/16W, 5%, 0603/1608 4723-331J+P 4
R347 330 OHM, RMG, 1/16W, 5%, 0603/1608 4723-331J+P 4
R348 330 OHM, RMG, 1/16W, 5%, 0603/1608 4723-331J+P 4
R367 560 OHM, RMG, 1/16W, 5%, 0603/1608 4723-561J+P 4
R369 10K, RMG, 1/16W, 5%, 0603/1608 4723-103J+P 4
R370 2.2K, RMG, 1/16W, 5%, 0603/1608 4723-222J+P 4
R371 1M, RMG, 1/16W, 5%, 0603/1608 4723-105J+P 4
R372 10K, RMG, 1/16W, 5%, 0603/1608 4723-103J+P 4
R373 10K, RMG, 1/16W, 5%, 0603/1608 4723-103J+P 4
R374 10K, RMG, 1/16W, 5%, 0603/1608 4723-103J+P 4
R377 330 OHM, RMG, 1/16W, 5%, 0603/1608 4723-331J+P 4
R378 330 OHM, RMG, 1/16W, 5%, 0603/1608 4723-331J+P 4
R379 10K, RMG, 1/16W, 5%, 0603/1608 4723-103J+P 4
R380 10K, RMG, 1/16W, 5%, 0603/1608 4723-103J+P 4
R381 10K, RMG, 1/16W, 5%, 0603/1608 4723-103J+P 4
R382 10K, RMG, 1/16W, 5%, 0603/1608 4723-103J+P 4
R383 10K, RMG, 1/16W, 5%, 0603/1608 4723-103J+P 4
R384 10K, RMG, 1/16W, 5%, 0603/1608 4723-103J+P 4
R651 10 OHM, RMF, 1W, 5%, ATS, METAL OXIDE 4718-100J+C-X 4
R652 100 OHM, RMG, 1/10W, 5%, 0805 4720-101J+J 4
