Bose FreeSpace DXA 2120

22
ELECTRICAL PART LIST
Capacitors
Digital Signal Processor (DSP) PCB Assembly
Reference
Designator
Description Vendor Part Number Note
C201 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C202 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C203 10uF, CE, 16V, 20%, RLT, 4x7, NICHICON 157D-106M+K-GMK 4
C204 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C205 47uF, CE, 16V, 20%, RLT, 5X7, ELNA 157D-476M+K-IME 4
C206 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C207 47uF, CE, 16V, 20%, RLT, 5X7, ELNA 157D-476M+K-IME 4
C208 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C209 22uF, CE, 16V, 20%, RLT, 4X7 157D-226M+K-GM 4
C210 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C211 2200pF, CC, 50V, 10%, 0603, 0.8x1.6 150F-222K+P-AC 4
C212 2200pF, CC, 50V, 10%, 0603, 0.8x1.6 150F-222K+P-AC 4
C213 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C214 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C215 10uF, CE, 16V, 20%, RLT, 4x7, NICHICON 157D-106M+K-GMK 4
C216 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C217 47uF, CE, 16V, 20%, RLT, 5X7, ELNA 157D-476M+K-IME 4
C218 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C219 47uF, CE, 16V, 20%, RLT, 5X7, ELNA 157D-476M+K-IME 4
C220 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C221 22uF, CE, 16V, 20%, RLT, 4X7 157D-226M+K-GM 4
C222 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C223 2200pF, CC, 50V, 10%, 0603, 0.8x1.6 150F-222K+P-AC 4
C224 2200pF, CC, 50V, 10%, 0603, 0.8x1.6 150F-222K+P-AC 4
C225 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C226 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C227 10uF, CE, 16V, 20%, RLT, 4x7, NICHICON 157D-106M+K-GMK 4
C228 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C229 47uF, CE, 16V, 20%, RLT, 5X7, ELNA 157D-476M+K-IME 4
C230 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C231 47uF, CE, 16V, 20%, RLT, 5X7, ELNA 157D-476M+K-IME 4
C232 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C233 22uF, CE, 16V, 20%, RLT, 4X7 157D-226M+K-GM 4
C234 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C235 2200pF, CC, 50V, 10%, 0603, 0.8x1.6 150F-222K+P-AC 4
C236 2200pF, CC, 50V, 10%, 0603, 0.8x1.6 150F-222K+P-AC 4
C237 10uF, CE, 16V, 20%, RLT, 4x7, NICHICON 157D-106M+K-GMK 4
C238 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C239 10uF, CE, 16V, 20%, RLT, 4x7, NICHICON 157D-106M+K-GMK 4
C240 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C241 10uF, CE, 16V, 20%, RLT, 4x7, NICHICON 157D-106M+K-GMK 4
C242 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C243 10uF, CE, 16V, 20%, RLT, 4x7, NICHICON 157D-106M+K-GMK 4
C244 10uF, CE, 16V, 20%, RLT, 4x7, NICHICON 157D-106M+K-GMK 4
C245 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
