Bose FreeSpace DXA 2120

23
ELECTRICAL PART LIST
Capacitors (continued)
Digital Signal Processor (DSP) PCB Assembly
Reference
Designator
Description Vendor Part Number Note
C246 10uF, CE, 16V, 20%, RLT, 4x7, NICHICON 157D-106M+K-GMK 4
C247 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C248 10uF, CE, 16V, 20%, RLT, 4x7, NICHICON 157D-106M+K-GMK 4
C249 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C250 10uF, CE, 16V, 20%, RLT, 4x7, NICHICON 157D-106M+K-GMK 4
C251 10uF, CE, 16V, 20%, RLT, 4x7, NICHICON 157D-106M+K-GMK 4
C252 10uF, CE, 16V, 20%, RLT, 4x7, NICHICON 157D-106M+K-GMK 4
C253 2700pF, CC, 50V, 10%, 0603/1608 150F-272K+P-AC 4
C254 2700pF, CC, 50V, 10%, 0603/1608 150F-272K+P-AC 4
C255 470pF, CC, 50V, 10%, 0805, 1.2X2.0 150F-471K+J-BD 4
C256 470pF, CC, 50V, 10%, 0805, 1.2X2.0 150F-471K+J-BD 4
C257 10uF, CE, 16V, 20%, RLT, 4x7, NICHICON 157D-106M+K-GMK 4
C258 10uF, CE, 16V, 20%, RLT, 4x7, NICHICON 157D-106M+K-GMK 4
C259 10uF, CE, 16V, 20%, RLT, 4x7, NICHICON 157D-106M+K-GMK 4
C260 2700pF, CC, 50V, 10%, 0603/1608 150F-272K+P-AC 4
C261 2700pF, CC, 50V, 10%, 0603/1608 150F-272K+P-AC 4
C262 470pF, CC, 50V, 10%, 0805, 1.2X2.0 150F-471K+J-BD 4
C263 470pF, CC, 50V, 10%, 0805, 1.2X2.0 150F-471K+J-BD 4
C264 10uF, CE, 16V, 20%, RLT, 4x7, NICHICON 157D-106M+K-GMK 4
C265 10uF, CE, 16V, 20%, RLT, 4x7, NICHICON 157D-106M+K-GMK 4
C266 1000pF, CC, 50V, 5%, 0603, X7R 150F-102J+P-AC 4
C267 680pF, CC, 50V, 10%, 0805, 1.2x2.0 150F-681K+J-BD 4
C268 100pF, CC, 50V, 5%, 0603/1608, 1X2 150F-101J+P-AC 4
C269 10uF, CE, 16V, 20%, RLT, 4x7, NICHICON 157D-106M+K-GMK 4
C270 10uF, CE, 16V, 20%, RLT, 4x7, NICHICON 157D-106M+K-GMK 4
C271 1000pF, CC, 50V, 5%, 0603, X7R 150F-102J+P-AC 4
C272 680pF, CC, 50V, 10%, 0805, 1.2x2.0 150F-681K+J-BD 4
C273 100pF, CC, 50V, 5%, 0603/1608, 1X2 150F-101J+P-AC 4
C274 10uF, CE, 16V, 20%, RLT, 4x7, NICHICON 157D-106M+K-GMK 4
C275 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C276 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C281 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C282 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C287 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C288 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C289 10uF, CE, 16V, 20%, RLT, 4x7, NICHICON 157D-106M+K-GMK 4
C290 10uF, CE, 16V, 20%, RLT, 4x7, NICHICON 157D-106M+K-GMK 4
C291 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C292 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C293 10uF, CE, 16V, 20%, RLT, 4x7, NICHICON 157D-106M+K-GMK 4
C294 10uF, CE, 16V, 20%, RLT, 4x7, NICHICON 157D-106M+K-GMK 4
C295 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C296 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C297 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C298 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C299 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
