Procedural Instructions on the TSC
8
8- 2 Perfusor® compact, 2.1 gb
Functional Inspection
Switch on unit.
1. Switch on Perfusor and keep ON-button pressed for max. 20
sec. Check the screen display during this time. A device alarm
is triggered if the button is actuated for more than 20 sec.
2. The following information appears on-screen when the
button is released:
111.
1
222.
2
555.
5
AA Reference to the instructions
for use (hard- and soft-
ware group)
Last syringe type
3. An audible alarm sounds three times.
4. Open lock (drive head).
Check push-button sensor alarm. The piston rod symbol must
flash on the LC display if a syringe was not inserted.
5. Insert current step gauge in the OPS 50 ml slot and close
syringe holder.
The lock must engage automatically and the syringe symbol
in the LC display must not flash.
6. Confirm current step gauge as OPS with F-button. Program as
OPS syringe type beforehand if necessary.
7. Start pump with a delivery rate of 12.3 ml/h (key sequence 1
2 3).
The pump delivers. The delivery rate set must be displayed.
8. Open lock.
Alarm by buzzer and positive locking sensor alarm. Drive
stops. Lock must not engage in upper position.
9. Plug in MFC service connector and actuate the START button.
Drive delivers at 12.3 ml/h.
10. Change delivery rate to 96 ml/h (key sequence C 9 6 F) during
infusion.
The pump delivers. The delivery rate set must be displayed.
Fig.: 8 - 1 Current step gauge
2.1
