Method 1: Click the [Rotate] icon on the left. Three rings at right angles
to each other are then displayed around the object. Click on a ring and make a
rotation around the current axis. You can then see the angle of rotation and the
direction in the middle of the ring. This allows you to rotate the model around
the X/Y/Z axes.
Method 2: Click the [Rotate] icon on the left, and then enter the rotation
angle values for positioning for the X/Y/Z axes. Click [Reset] to reset the rotation
angle values.
6.2.7 Scaling
Select the desired object and scale it using one of the following two methods:
Method 1: Click on the symbol [Scale] on the left, keep the left mouse
button pressed and scale the model. The corresponding values are displayed
next to the object.
Method 2: Click the [Scale] icon on the left, and then enter the
positioning scale values for the X/Y/Z axes. Click the [Maximum] button to
achieve the maximum possible size for printing. Click [Reset] to reset the size
of the model.
Note: If you clicked the [Uniform Scaling] radio button, the model will be scaled
to scale when you change any value of the model's positioning. Otherwise, only
the corresponding item value is changed.
6.2.8 Cutting
Left-click the model to select it, then double-click the "Cut" icon to set
the cut plane. You can set the direction and the position.
