C Internal compensation: If you activate this option, the software can make
adjustments for inner diametre errors.
Save as new
This option allows the model to be saved to a new file after parametre changes.
Proceed as follows:
After all required parametres have been changed, click on [Save as new]. This
opens a dialogue box. In this field, you must enter a file name and then click
[OK]. Click the drop-down menu of [Select profile]. The newly added schema
will appear in the list.
Remove
This option allows you to delete the added schemas. Select one of the added
schemes and click [Remove]. A dialog box will then open where you can confirm
the process. Click [Yes] to delete the scheme, or click [No] to cancel the current
operation.
Restore Defaults: With this option the default values can be restored.
Save Configuration: With this option the current configuration can be saved.
8.1 Things to know about supports
(Reference video: Interesting facts about supports)
If you want to print models with steep overhangs and cantilevered areas, you
need support structures. The 3D printer uses FFF (Fused Film Film Layering)
technology, which is based on the principle of additive manufacturing, i.e.
heating and applying material in layers to create an object. Many 3D printed
models require a layer of material to be applied where there is no layer, or the
models have acute angles that could cause unwanted drops to form during
printing. In such cases, support structures are required to ensure proper printing
and the desired print quality.
① The 45 degree principle
Basically it can be stated that for 3D models with an overhang of more than 45º
