background is not drawn. With option OPT_NOTICKS, the tick marks are not
drawn. With option OPT_NOPOINTER, the pointer is not drawn.
major
Number of major subdivisions on the dial, 1-10
minor
Number of minor subdivisions on the dial, 1-10
val
Gauge indicated value, between 0 and range, inclusive
range
Maximum value
Description
The details of physical dimension are
The tick marks are placed on a 270 degree arc, clockwise starting at south-
west position
Minor ticks are lines of width r*(2/256), major r*(6/256)
Ticks are drawn at a distance of r*(190/256) to r*(200/256)
The pointer is drawn with lines of width r*(4/256), to a point
r*(190/256)from the center
The other ends of the lines are each positioned 90 degrees perpendicular to
the pointer direction, at a distance r*(3/256) from the center
Refer to Co-processor engine widgets physical dimensions for more information.
Command layout
