+18
Range
Examples
A gauge with radius 50 pixels, five divisions of four ticks each, indicating 30%:
cmd_gauge(80, 60, 50, 0, 5, 4, 30, 100);
Without the 3D look:
cmd_gauge(80, 60, 50, OPT_FLAT, 5, 4,
30, 100);
Ten major divisions with two minor divisions each:
cmd_gauge(80, 60, 50, 0, 10, 2, 30,
100);
