 REG_CTOUCH_RAW_XY Definition
31 16 15 0
Reset Value: 0xFFFFFFFF
Note: This register is only available in compatibility mode
Bit 0 - 15 : The value of these bits are Y coordinates of touch point but before going
through transform matrix
Bit 16 - 31: The value of these bits are X coordinates of touch point but before going
through transform matrix
REG_CTOUCH_RAW_XY Definition
Address: 0x102508
RO
RO
 REG_CTOUCH_TAG Definition
This register is available in both mode. In extended mode, only the first touch point, i.e.,
REG_CTOUCH_TOUCH0_XY is used to query the tag value and update this register with
the result. It shares the same definition with REG_TOUCH_TAG.
