Register Definition 68 REG_SCREENSHOT_START Definition
R/W
31 1 0
Address: 0x102418
Reset Value: 0x0
Note: NONE
Bit 0 : Set this bit to start screen shot if screen shot is already enabled. Screen shot is
automatically stopped when screen shot is disabled.
Bit 1~31: Reserved.
REG_SCREENSHOT_START Definition
Reserved
Register Definition 69 REG_SCREENSHOT_Y Definition
31 9
Address: 0x102414
Reset Value: 0x000
Note: NONE
Bit 0~8 : The value of these 9 bits specifies the line number to capture in horizontal direction
when screen shot is enabled.
Bit 9~31: Reserved.
REG_SCREENSHOT_Y Definition
8 0
Reserved
R/W
Register Definition 70 REG_SCREENSHOT_EN Definition
R/W
31 1 0
Address: 0x102410
Reset Value: 0x0
Bit 0 : Set this bit to enable screen shot for current frame. Clear this bit to disable the screen
shot.
Bit 1-31: Reserved.
REG_SCREENSHOT_EN Definition
Reserved
