CHAPTER 5 DISASSEMBLY AND RE-ASSEMBLY
Confidential
5-54
(3) Remove the LCD from the LCD holder.
Fig. 5-82
(4) Remove the Back light film from the LCD holder.
Fig. 5-83
LCD holder
LCD
LCD holder
Back light film
