Brother HL-5280DW Service Manual

CHAPTER 1 GENERAL
Confidential
1-8
3.2 Functions
<Controller>
Processor 266MHz
Emulation BR-Script 3 (PostScript

3
TM
), HP LaserJet (PCL6), Epson FX-850 and
IBM Proprinter XL
Memory <Standard>
16 MB (HL-5240) 32MB (HL-5250DN/5270DN/5280DW)
<Option>
DIMM
(HL-5240)
The HL-5240 printer has 16 MB of standard memory and one slot for
optional memory expansion. You can expand the memory up to 528
MB by installing dual in-line memory modules (DIMMs).
(HL-5250DN/5270DN/5280DW)
The HL-5250DN/5270DN/5280DW printer has 32 MB of standard
memory and one slot for optional memory expansion. You can
expand the memory up to 544 MB by installing dual in-line memory
modules (DIMMs).
“DIMM types”
You can install the following DIMMs:
• 128 MB Buffalo Technology VN133-D128/ VN133-X128
• 256MB Buffalo Technology VN133-D256
• 512MB Buffalo Technology VN133-D512
• 64 MB TechWorks 12165-0004
• 128 MB TechWorks 12462-0001
• 256MB TechWorks 12485-0001
• 512MB TechWorks 12475-0001
In general, the DIMM must have the following specifications:
Type: 144 pin and 64 bit output
CAS latency: 2
Clock frequency: 100 MHz or more
Capacity: 64, 128, 256 or 512 MB
Height: 31.75 mm (1.25 in.)
Dram Type: SDRAM 2 Bank
SDRAM can be used.
NOTE:
There might be some DIMMs that will not work with the printer.
Interface Standard:
HL-5240 HL-5250DN/5270DN HL-5280DW
Hi-Speed USB 2.0
IEEE 1284 Parallel
Hi-Speed USB 2.0
IEEE 1284 Parallel
10/100 BASE-TX
Hi-Speed USB 2.0
IEEE 1284 Parallel
10/100 BASE-TX
Wireless LAN
IEEE802.11 b/g
Option:
HL-5240 HL-5250DN/5270DN HL-5280DW
10/100 BASE-TX
Ethernet (NC-2100p)
N/A N/A
