S-7300A
6. USING THE OPERATION PANEL (ADVANCED OPERATIONS)
50
6-9. List of memory switch settings
Presser foot lifter and treadle settings (001 to 099)
No. Setting range
Initial
value
Setting
units
Setting details
001
ON/OFF
(*1)
－
When treadle is returned to neutral after thread trimming, presser foot is
raised up
ON: Presser foot is raised
OFF: Presser foot is not raised
(*) The presser foot lifts when MSW-851 is set to "OFF".
(Refer to the Service Manual for details on MSW-851.)
002
ON/OFF
OFF
－
After treadle stops at neutral, presser foot is raised up
ON: Presser foot lifts
OFF: Presser foot is not lifted
003
ON/OFF
ON
－
After treadle stops at neutral, presser foot is possible to raised up when
treadle depressed one step backward.
ON : Enabled
OFF: Disabled
004
ON/OFF
ON
－
When treadle depressed backward, thread trimming and end backtack
sewing is possible.
ON: Thread trimming and end backtack sewing operations are enabled
(However, if thread trimming operation is locked, needle up operations
will be carried out without thread trimming.)
OFF: Thread trimming and end backtack sewing operations are disabled
(presser foot lifts when the treadle is depressed backward)
010
ON/OFF
OFF
－
After standing up pedal is used, treadle operation is possible.
(Alternating operation is possible)
(*) For simultaneous operation which includes operation of the presser foot
lifter pedal, operation of the standing operation pedal takes priority.
ON: Treadle operation is still enabled after standing operation pedal has
been used (alternating operation is possible)
OFF: Treadle operation is disabled after standing operation pedal has been
used
011
0 - 1
0
1
Operation when standing up variable speed pedal is ON
0: Sewing speed corresponds to treadle depression amount
1: Sewing speed corresponds to sewing speed set for main sewing
(constant speed)
012
0 - 500
(ms)
80
(ms)
10
(ms)
Delay time from standing pedal turning on until motor starts operating
013
ON/OFF
ON
－
When AUTO function is set ON, pauses when presser foot pedal is ON.
ON: Sewing is interrupted when presser foot lifter pedal turns on (pause
operation)
OFF: No operation
014
ON/OFF
ON
－
When AUTO function is set ON, it can be changed ON/OFF of motor
operation by slightly pressing high speed pedal.
ON: Motor operation switches on/off each time the high-
speed pedal is
depressed slightly to ON and back to OFF
OFF: Disabled (sewing machine motor does not stop)
015
ON/OFF
ON
－
After thread trimming, possible to lift up and down by thread trimming
pedal
ON: Presser foot can be raised and lowered
(*) If MSW-
051 is set to "ON", thread trimming pedal operation is disabled
after the presser foot lifter pedal has been operated during standing
operation.
(Refer to the Service Manual for details on MSW-051.)
OFF: No operation (only possible using presser foot lifter pedal)
(*1) Other than Europe and America: ON
Europe and America: OFF
