CONTROLS, INSTRUMENTS AND EQUIPMENT
mmo2007-009-066_k
F) Clock
NOTE: This clock diplays in the
24-hour format only.
Press the SET (S) button to select clock
mode.
mmo2007-009-066_p
1. Clock mode
G) Fuel Level
Bar gauge that continuously indicates
the amount of fuel left in the fuel tank.
mmo2007-009-042_a
FUEL LEVEL
1. Operating range
H) Altitude
Displays vehicle approximate altitude
above sea level calculated from the
barometric pressure.
NOTE: Altitude displayed is rounded
off every 100 meters (gauge set in
metric) or 200 feet (gauge set in impe-
rial units).
To display vehicle altitude, proceed as
follows.
Press the MODE (M) button to select
display 2.
mmo2007-009-066_m
While display is flashing, press the SET
(S) button to select altitude mode.
mmo2007-009-066_k
The following symbol appears when al-
titude mode is selected.
mmo2008-003-023
ALTITUDE MODE
Press the MODE (M) button to confirm
selection or wait 5 seconds.
56
