CONTROLS, INSTRUMENTS AND EQUIPMENT
2. Insert the lower section of side
panel over the aluminium chassis
and the aluminium tab into the panel
slot.
mmo2009-004-047_a
1. Lower section
2. Aluminium chassis
3. Aluminium tab
4. Panel slot
3. Insert the panel dowel into the tun-
nel hole.
mmo2011-006-102_a
1. Dowel
2. Tunnel hole
4. Hook the rubber tie.
5. Lock the clip by turning it 1/4 turn
clockwise.
Lower Side Panel Removal/
Installation
1. Open lower side panel as expl
ained
above.
2. Lift the front of side pane
l and free
the lower hinge from its slot.
3. Free the upper hinge by
lowering
the panel.
Reverse procedure for
installation.
30) Rewind Starter Handle
(If Equipped)
Auto-rewind type located on right hand
side of snowmobile behind side panel.
To engage mechanism, pull handle
slowly until a resistance is felt then pull
vigorously. Slowly release handle.
31) Spark Plug Storage
A space is provided in the tool kit to
keep spare spark plugs dry and pre-
vent shocks that might affect the ad-
justment or break them.
NOTE: Spare spark plugs are not sup-
plied with snowmobile.
NOTE: Check s pa re spark plug gap a c-
cording to
SPECIFICATIONS
before in-
stallation.
CAUTION Do not attempt to
adjust spark plug gap.
32) Fuel Tank Cap
Unscrew to fill up tank then fully
tighten.
WARNING
Always stop the engine before re-
fueling. Fuel is flammable and ex-
plosive under certain conditions.
Always work in a well ventilated
area. Do not smoke or allow open
flames or sparks in the vicinity.
Open cap slowly. If a differen-
tial pressure condition is noticed
(whistling sound heard when loos-
ening fuel tank cap) have vehicle
inspected and/or repaired before
further operation. Do not overfill
or top off the fuel tank before plac-
ing the vehicle in a warm area. As
temperature increases, fuel ex-
pands and might overflow. Al-
ways wipe off any fuel spillage
from the vehicle. Periodically ver-
ify fuel system.
70
