TUNE YOUR RIDE
NOTE: If the specification is unattain-
able with the original springs, see an
authorized Lynx dealer for other avail-
able springs.
NOTICE
To increase spring
preload, always turn the left side
adjustment cam in a clockwise di-
rection, and the right side cam in a
counterclockwise direction.
Load Capacity Adjustment (If
Equipped)
Models equipped with EasyRide
suspension
EasyRide suspension has an additional
adjustment for the rear suspension
load capacity.
NOTICE
The adjustment must al-
ways be tightened all the way to ei-
ther end of the adjustment. Do not
leave the adjustment in between of
these positions, damage can occur.
To adjust proceed as follows:
Hard Setting
619900954-502_a
TURN HANDLE ALL THE WAY CLOCKWISE -
HARDER SUSPENSION
Tu rn handle clockwise completely for
harder suspension.
NOTE: Ensure the limiter is touching
the rear arm bracket.
619900696-010
So ft Se tting
619900954-502_b
TURN HANDLE ALL THE WAY
COUNTERCLOCKWISE - SOFTER
SUSPENSION
Tu rn handle counterclockw ise com-
pletely for softer suspension. (Factory
setting)
NOTE: Ensure the limiter is touching
the rear arm tube.
619900696-009
88
