Measuring Ampifier Type 2525
User Manual Vol.1
Brüel & Kjær
5–10
Chapter 5 –The Measurement Set-up Menu
Detector DC Output
5.12 Detector DC Output
This menu allows you to select which data appears at the amplifiers’s detector
output (at the auxiliary connector on the rear of the amplifier).
The options are:
RMS*
+PEAK
–PEAK
PEAK-TO-PEAK
0V
1V
The 0 and 1V options are used for calibration of output to the DC recorder.
Output is digitally generated and updated at 125ms intervals (the same interval as
the LCD meter is updated).
