Running the minispec mq20 Toothpaste Analyzer
E1400912_1_001 33
7 Running the minispec mq20
Toothpaste Analyzer
7.1 mq20 Toothpaste Analyzer On Temperature
Once all LEDs on the mq20 Toothpaste Analyzer have switched to green, the system is
ready to run.
The PC that has been started will pause at the Windows log-in window. When configured by
Bruker, no password has been entered and the user may proceed by pressing Enter. The PC
will then finish the boot-up process and show the minispec Plus icon on the desktop. Besides
the software icon, a link to the “minispec documentation” folder is also on the desktop.
7.2 Running minispec Plus Software
Double-click on the minispec Plus icon to start the software. The software will start and come
to the log-in screen.
Figure7.1: The minispec Plus Log-in Dialog
To get full access to all the menus of minispec Plus, type ADMIN and press the Enter button.
