Running the minispec mq20 Toothpaste Analyzer
E1400912_1_001 41
Afterwards switch back to the main menu of minispec Plus to start running measurements of
unknown samples.
7.4 Measurements of Unknown Samples
When the calibration(s) is(are) finished, one may switch to the “Measurement” section. Here
unknown samples are analyzed and measured according to the calibration curve selected by
the user.
• Enter the batch name of the sample to be analyzed.
• Select the corresponding calibration method. Note: once batch and calibration are chosen,
those are connected to each other. The software then remembers this connection when
doing further measurements.
• Depending upon the method, as it has been defined during the calibration, the sample
may need to be weighed. Enter the corresponding sample weight into the software or get
the mass transferred from the balance connected.
