minispec.exe Software for Diagnostic and Service Purposes
58 E1400912_1_001
The Instrument Settings Command
Minispec instrument settings (see the figure below) are instrument dependent values such as
the pulse lengths and the magnetic field at NMR resonance. Instrument settings differ from
minispec to minispec, and must be tuned the first time a minispec is connected. You can use
this command to change the settings of the instrument with manual input.
Figure8.8: The minispec Settings Table
You can change the listed settings by manual input or with the Update Settings and Daily
Check commands. Greyed entries are disabled.
Shortcut: Standard Tool Bar:
The settings that can be changed are shown in the figure above. If the minispec Settings
are disabled on a connected minispec, customize your minispec software (through the
Welcome Box) to access the calibration parameters.
The Advanced button in the settings table allows access to a list of instrument setting table
names. The user may select the appropriate settings table to be used by the instrument,
define custom names for the settings tables with the help of the Customise button (e.g.
settings table name could be set to the probe name), and save the current entries under a
new name.
The Tune Settings Command
When the minispec is first connected to the PC, all instrument settings must be tuned starting
from default values. This can be done with the Tune Settings command. The routine will
tune all settings of the instrument without user prompting. If the Tune Settings menu stays
disabled on a connected minispec, customize your minispec-software to get access to the
calibration parameters.
The Update Settings Command
A blue mark (validated) symbol on the right side of the Info Toolbar indicates a well checked
minispec instrument.
