minispec.exe Software for Diagnostic and Service Purposes
E1400912_1_001 59
An update of the instrument settings can be done periodically to check the instrument validity.
An update may be necessary after the system has been relocated or the probe assembly has
been changed. An instrument settings update is also recommended if the Daily Check fails.
The Update Settings routine is faster than the Tune Settings routine, as it starts from pre-
adjusted settings (listed in the current instrument setting table). The Update Settings routine
also the update of selective settings, whereas the Tune Settings command will tune all
settings without further user prompting. For instrument optimization it is recommended using
the Update Settings routine. For the initial tuning of the settings, the Tune Settings is the
method of choice.
If the Update Settings menu stays disabled on a connected minispec, customize your
minispec software (through the Welcome Box) to provide access to the calibration
parameters.
The Daily Check Command
This option tests the instrument tuning but does not change the instrument settings. A quick
check is recommended once a day (every 24 hours). A checkmark (Checked) in the Info
Toolbar signifies a well-checked minispec instrument. An un-calibrated minispec instrument is
indicated by a yellow mark (Check!).
To run the Daily Check, use the corresponding toolbar button or select Daily Check from the
menu. If one of the checks fails it indicates that an instrument setting is not optimized. Use
the Update Settings command to perform an update.
Shortcut: Info Toolbar:
The Balance Settings Command
One can connect a scale by serial interface to the PC's communication port in order to
electronically transfer sample weight information (weights are necessary for some absolute
applications). To enter the port configuration dialog, close all minispec applications, then
select Balance from the Setup menu. Access is limited to users who have permission to
enter the minispec main menu or calibration. Select the balance type, then the port to
connect the balance to. Select the port parameters according to the settings on the scale. To
set the standard values, click <Default> before leaving the Settings Table. To leave the
Settings Table unchanged, click <Cancel>. To re-load old settings from file after
modifications, click <Re-Read>. To leave the Settings Table with the new values, click <OK>.
The I/O Port Settings Command
One can connect serial interface devices, such as balances, thermostats or sample
changers, to the PC's communication port. To get the port configuration dialog, close all
minispec applications, then select 'I/O Port' from the 'Setup' menu. Note: To get the minispec
main menu, the R&D level or calibration permission must be given. Select the port
parameters according to the settings on the connected device.
