Additional programming options
8
Logamatic 4211 - Subject to technical modifications.
63
8.4 Creating a new DHW circulation pump program
You can operate the DHW circulation pump either according to the factory
settings "Program select. by heat. circs" or according to your own new switching
program "Program select. own CP".
If your circulation pump should work independently of the heating circuits, you
can enter your own new DHW circulation pump program as follows:
Example:
The DHW circulation pump is to run on all weekdays from 06:30 to 09:00.
z Select a heating circuit (Æ Chapter 7.6).
(here: "DHW circulation")
z Select a program for the heating circuit "DHW circulation" (Æ Chapter 7.10).
(here: "Program select. new")
The display shows the blank screen "New switch.point" for the new switching
point.
z Enter the switching points (Æ Chapter 8.2).
Your DHW circulation pump will now operate according to your "Own program
CP". You can call up your new "Own program CP" by pressing "Prog" and
turning the rotary selector.
USER INFORMATION
With the factory setting "Program select. by heat circs", the DHW circulation
pump will automatically start 30 minutes before the first switching point of all
heating circuits associated with this control unit, and end when the last heating
circuit is stopped.
USER INFORMATION
Only after all three details (day/time/temperature) have been defined for the
new switching point will it be automatically saved under "Own program CP" and
the heating circuit number "DHW circulation". The saving process is not shown
on the display. The display shows the blank screen "New switch.point" for the
next switching point. Repeat this process for all required switching points.
