Product description
Logamax plus GB162-80 kW/100 kW - Subject to modifications resulting from technical improvements!
3
1: BC10 basic controller receptacle
2: Installation option for room controller, e.g. RC35
3: Cover with user manual compartment
4: BC10 basic controller, can be expanded e.g. by the RC35 room controller
5: Connection box (low-voltage and 120 VAC connections)
6: Fan harness and mains lead of the pump
7: Condensate drain outlet
8: Condensate collector
9: Boiler front door
10: Automatic air vent
11: Retaining clips
12: Air intake for the fan
13: Gas pipe
14: Flue gas pipe
15: Door lock
16: Flue gas sensor
17: Flue measuring point
18: Measuring point for air intake
19: Flue gas connection
20: Air intake connection
21: Fan
22: Gas valve
23: Venturi
24: Burner cover
25: Flow temperature sensor
26: Ionization electrode
27: Sighting glass
28: Glow ignitor
29: Safety temperature sensor
30: Heat exchanger
31: Pressure sensor
32: Return temperature sensor
33: Universal Burner Automatic Version 3 (UBA 3)
34: Draw with function module integration options
35: Cover shield
36: Condensate trap
Pump group (scope of delivery):
37: Isolating valve, blue (CH boiler return) with pump, drain cock, check valve and thermometer
38: Manual gas shutoff valve, yellow (GAS)
39: Isolating valve, red (CH boiler flow) with drain cock, pressure gauge and thermometer
40: Pressure gauge
41: Isolating valve
42: Thermometer (optional accessory)
43: Drain valve
44: Safety valve 30 psi (2 bar) (or 50 psi [3.45 bar] = optional)
The pump group also includes an insulation cover (see also pump group installation instructions).
Low loss header (scope of delivery, single appliance only):
45: Low loss header (not illustrated)
