Spare parts16
Logamax plus GB162-80 kW/100 kW - Subject to modifications resulting from technical improvements!88
16 Spare parts
The following are parts commonly required due to damage or replacements. Their failure will affect safety or performance
of this appliance. For a pictorial representation of the part see the respective position number on the exploded view pictures
on page 89 and 90.
Description Product No. Description Product No.
1 Door 7746900396 61 Cover controller BC10 73698
2 Sealing door 73912 62 Burner 73917
3 Door lock 73911 63 Seal Burner 73918
4 Hinge door 73990 64 Clamp (2 pc) 73921
5 Wall mounting bracket 73965 65 Burner box 73919
6 Bracket left 73962 66 Front connection board 73910
7 Bracket right 73963 67 Controller connection plate 73692
8 Adjusting foot 73949 68 On/Off switch 73660
9 Transport slide (L + R) 73951 69 Knob BC10 38724
10 Drawer modules 73964 70 Draw connection board 73909
11 Screw 4.2 x 8.5 x (10 pc) 73988 71 Cover control box 73977
12 Condensate collector 73930 72 Cover connection board 120 VAC 73815
13 Seal condensate collector 73929 73 Transformer 73697
14 Seal Ø 80 mm (3.2”) 73931 74 UBA 3 18196
15 Upper side condensate collectors 73934 75 Fuse 5AF (10 pc) 73904s
16 Mounting flue-gas pipe 73907 76 Connection board 73814
17 Exhaust pipe 73935 77 Electronic connection red 73776
20 Condensate collector 73933 78 Electronic connection grey 73774
21 Seal condensate collector 73463 79 Electronic connection green 73773
22 Drain pipe 73932 80 Electronic connection blue 73775
23 Sealing bush (white) 73449 81 Electronic connection orange 73777
24 Condensate drain pipe 73995 82 Flue gas exhaust connection 73940
25 Fan 7746900382 83 Flue gas adapter 73936
26 Seal Fan 73920 84 Measure niple cap 73937
27 O-ring 70 x 3 (2 pc) 73983 85 Seal 150 mm 73968
28 Venturi 73978 86 Cable harness low voltage 7746900392
29 Seal Ø 60 mm (2.4”) 73563 87 Cable harness high voltage 7746900393
30 Gas valve 7746900399 88 Cable harness on/off switch 73946
31 Seal 33 x 24 x 3.5 (10 pc) 73368s 89 Cable harness earth 73947
32 Gas pipe – 100 kW 7746900397 90 Mains cable (cable harness) 7101471
with gas nipple 774601394A 91 Union nut 1½" (5 pc) 73481s
33 Flange Gas valve 73987 92 Sealing (10 pc) 15022s
34 O-ring (10 pc) 73982 93 Nut 1" 73675
35 Orifice 100 kW 73980 95 Gas valve 7746900401
36 Screw M5 x 20 (10 pc) 73572s 96 Pump UP26-99U 7746900402
37 Screw M5 x 16 (10 pc) 73970 97 Air vent 73409
38 Screw M6 x 16 (10 pc) 73971 100 Casing 73961
39 Air intake for the fan – 100 kW 73926 101 Thermometer 7746900404
40 Sealing (10 pc) 73969 102 Manometer 73958
41 Air vent revision set 73916 106 Safety valve 4 bar 7746900403
42 Clip 73973 107 Connection pressure gauge 73081
43 Sensor NTC 7746900391 108 Drain pipe 73075
44 Clip (3 x 2 pc) 78156s 109 Valve housing supply (combi) 7746900406
45 O-ring 9.19 x 2.62 (10 pc) 78175s 110 Adapter parallel 4” 7746900384
46 Pressure sensor 73915 111 Adapter insert 4” 7746900385
47 O-ring 14 x 1.78 (10 pc) 73679s 112 Open venting insert 7746900386
48 Return/Supply pipe 73950 113 Lipring 114 7746800387
49 Connection nipple CH 73080 114 Lipring 103 7746800388
50 Clip 73974 117 Strain relief bracket 7746900398
51 O-ring (10 pc) 73972 118 Safety valve ASME 7746900405
52 Flue gas sensor 7746700420 119 Low loss header 7746901103A
56 Mounting set with sight glas 8718600172 120 Plug protector 73948
with glow ignitor
with ionization electrode – BCM 1100 – 100 kW (0-4,000 ft) 7746900394
– BCM 1101 – 80 kW (0-4,000 ft) 7746900395
60 Heat exchanger 7746900383 – Screw 6.3 x 19 (10 pc) 73986
