2 Burner installation
32 Installation and maintenance instructions Logano GE315 • Issue 02/2006
We reserve the right to make any changes due to technical modifications.
z Insert cable clips with fitted cables into the clip frame
and secure by pivoting the lever
(Fig. 47, Item 1).
z Hook the rear wall (Logamatic 43..) with the lower
hooks into the clip frame and push the top part home,
until the hooks engage
(Fig. 44, Item 2).
z Fit the terminal cover (Fig. 43, Item 1) with two self-
tapping screws and secure on the control unit base
(Fig. 48).
Fig. 47 Securing the electrical connection cables
Fig. 48 Boiler with control unit installed
1
