Buffalo TeraStation - Using RAID 5 mode (3 hard drives)

TeraStation User Manual 21
Change system to normal mode (previous page).1
2
3
4
5
Note:
After the RAID array is changed, the TeraStation will perfom a RAID check that will take about 5 hours per TB. File
transfers will be slower during this period. While the “RAID ARRAY x Resyncing” message is displayed on the LCD
screen, do not turn o the TeraStation. If you turn it o, the RAID check will start over.
The [Conrm Operation] screen will appear. 6
Enter the number shown in the [Conrmation Number] eld within 60 seconds, and click [Apply].
Follow the instructions displayed on the screen.7
You have now set up a RAID 5 array. Turn to page 43 to create a shared folder.
Click the array you want to congure.
Select [RAID5].1
Click [Create Raid Array].2
Select hard disks (all 4 of them) to use in RAID5.
Using RAID 5 mode (4 hard drives)
Click [System] - [Storage] - [RAID Array] in the Web Admin interface.
