Assembly
D
Inserttheduplicationsystem→
"D"intothestrokelimiter.
D
Tightentheduplication→
system"D"untilfreecontact
isobtainedwiththetopof
thelimiter,usingaflatNo27
spanner.
D
Fullytightentheduplication→
rodontheactuatorrodusing
ascrewdriverwithabladeof
suitablesize.
Depressurizetheactuatorofa
→
valvewhichisnormallyclosed
(function"A")orhasadouble
effect(function"I"):thevalve
recoversitsdefaultposition.
