Burkert 8202 ELEMENT Quick Start

11
Technical data
Type 8202/8222
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
0 +20 +40 +60
T (°C)
P (bar)
PVC + PP
-20
232
217.6
203
188.6
174
159.6
145
130.6
116
101.6
87
72.5
58
43.5
29
14
0
P (psi)
Metal
Fig. 4: Fluid temperature / pressure dependency of the 8202 (without the probe) or the
8222, with a PVC nut and a metal, PVC or PP S022 adapter
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
-20 0 +20 +40 +60 +80 +100 +140
PVC
PP
T (°C)
P (bar)
PVC + PP
+120
232
217.6
203
188.6
174
159.6
145
130.6
116
101.6
87
72.5
58
43.5
29
14
0
P (psi)
Metal
Fig. 5: Fluid temperature / pressure dependency of the 8202
(without the probe) with a PVDF nut and a metal, PVC or
PP S022 adapter
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
-20 0 +20 +40 +60 +80 +100 +140
PVC
PP
T (°C)
P (bar)
PVC + PP
+120
232
217.6
203
188.6
174
159.6
145
130.6
116
101.6
87
72.5
58
43.5
29
14
0
P (psi)
Metal
Fig. 6: Fluid temperature / pressure dependency of the 8222, with
a PVDF nut and a metal, PVC or PP S022 adapter
Part Material
Box / seals stainless steel 1.4561, PPS /
EPDM
Cover / seal PC / EPDM
Display module PC / PBT
M12 fixed connector nickel-plated brass
Fixed connector holder stainless steel 1.4404 (316L)
Screws stainless steel
Nut PVC or PVDF
