31
Adjustment and commissioning
Type 8202/8222
You want to... Press...
...browse in the dynamic
functions bar (MEAS,
BACK, ABORT, OK, YES,
NO)
• next function:
• previous function:
...confirm the highlighted
dynamic function

...modify a numerical value
- increment the figure
selected
-
- decrement the figure
selected
-
- select the previous
figure
-
- select the next figure
-
- allocate the "+" or "-"
sign to the numerical
value
-
to the extreme left of the
numerical value then
until
the desired sign is displayed
- move the decimal
point
-
to the extreme right of
the numerical value then
until the decimal point is in the
desired place
9.3. Using the dynamic functions
You want to... Choose...
...go back to the READ level,
without validating the modifica-
tions made
dynamic function "MEAS"
...validate the input dynamic function "OK"
...go back to the parent menu dynamic function "BACK"
... abort the current operation
and go back to the parent menu
dynamic function "ABORT"
...answer the question asked dynamic function "YES" or "NO"
English
