Description
5.4 Type label
8222 Conductivity Transmitter V2
Supply: 14-36V 40W Max.
Output: 1x 4-20mA 2x Trans. 1A Max
Cell:
C 1,00 Range 5-10000 µS/cm
Process: Temp:0...+50°C, PN 16 Bar
Limited by cell and materials fitting
IP65 -IP67
W41MT
FDA
S-N:2691
00xxxxxx
7
1:V+
2:NPN/PNP1
3:0V
4:NPN/PNP2
21
3
4
5
6
8
9
11
12
14
16
17
10
13
15
1. Type of the device, measured quantity
2. Device version
3. Maximum power consumption
4. Nominal pressure of the fluid. The nominal pressure that is given on the Type label of a Type 8222 ELEMENT
device is valid for a device without conductivity sensor.
5. Manufacturing code
6. Pin assignment of the electrical connection
7. Certification
8. Article number
9. Serial number
10. Conformity marking
11. Certification
12. IP-Code
13. The fluid temperature and the fluid pressure are limited by the conductivity sensor used and by the materials
of the fitting used
14. Temperature range of the fluid. The temperature range that is given on the Type label of a Type 8222
ELEMENT is valid for a device without conductivity sensor.
15. Specifications of the conductivity sensor
16. Specifications of the outputs
17. Operating voltage
Fig. 1 : Type label (example)
