Technical data
6.7 Sensor specifications
Conductivity sensor C=0.01
• Measurement range • 0.05...20 µS/cm
• Type of fluid • ultra-pure water, pure water
Conductivity sensor C=0.1
• Measurement range • 0.5...200 µS/cm
• Type of fluid
• pure water, industrial wastewater
Conductivity sensor C=1
• Measurement range • 5 µS/cm to 10 mS/cm
• Type of fluid
• industrial wastewater, wastewater
6.8 Data of connectors and cables
Number of fixed connectors Type of connector
1 male M12 fixed connector 5-pin female M12 connector (not supplied).
For the M12 connector with article number 917116, use a
shielded cable:
• diameter: 3...6.5 mm
• wire cross section: max. 0.75 mm
2
1 male M12 fixed connector and 1 female
M12 fixed connector
5-pin female M12 connector (not supplied) and 5-pin male M12
connector (not supplied).
For the M12 connector with article number 917116, use a
shielded cable:
• diameter: 3...6.5 mm
• wire cross section: max. 0.75 mm
2
English
Type 8222 ELEMENT
