Operating and functions
Tab. 4 : Scenario of a dosing with no problem nor pause
Event state, output DO4
no dosing
OFF
dosing
ON
end of the dosing
OFF
Tab. 5 : Scenario of a dosing with pause
Event state, output DO4
no dosing
OFF
dosing
ON
dosing interrupted
1Hz
dosing continued
•
ON
if the dosing is not finished
•
OFF
if the dosing finished during the pause
or reset the dosing
OFF
Tab. 6 : Scenario of a dosing with alarm
Event state, output DO4
no dosing
OFF
dosing
ON
ALARM
3.5 Hz
confirm the alarm
•
OFF
if the dosing finished during the alarm
•
1Hz
if the dosing is not finished: the dosing has
been interrupted.See Tab. 5.
